| Diameter pipa hisap |
1" |
| Diameter pipa dorong |
1" |
| Panjang pipa hisap(m) |
11 |
| Maksimal level air |
8m |
| Maksimal daya dorong |
43m |
| Total Head(m) |
35/39/42 |
| Kapasitas(liter/m) |
70/60/50 |
| Material spesification: |
| Body pompa |
Cast iron EN-GIL-200 |
| Support |
Cast iron EN-GIL-200 |
| Impeller |
Noryl GFN 2 |
| Diffuser |
Noryl GFN 2 |
| Shaft with rotor |
AISI 303 stainless steel X 10 Cr NiS 18.9Degree |
| Venturi tube and nozzle |
Noryl GFN 2 |
| Mechanical seal |
Carbon/ceramin |
| O-ring gasket |
NBR |
| Operasi dari 0.6 to 10.5 m3/h dengan maksimum head 63 metres |
| Temperature bendah cair |
0 Deg.C to +35 Deg.c for domestic use(safety regulation EN 60335-2-41) |
| Kriteria quality bendah cair, bersih, bebas dari bendah keras, kasar, material yang tidak aggresive +40Deg.C |
| Maksimum suhu lingkungan |
+40 Deg.C |
| Maksimum kedalaman menyedot |
8 metres |
