Bor Duduk Westlake MODEL:ZHX-13

Max Drilling Capacity	13mm
Diameter of column	48mm
Spindle Travel	50mm
Distance spindle axis to column surface	103mm
Max. Distance spindle nose to worktable	220mm
Max. Distance soindle nose to nose	300mm
Spindle Taper	B16
Spindle Speeds Range	515 - 2580rpm
Spindle speeds	5
Dimensions of worktable surface	165 x 162mm
Dimension of base worktable surface	178mm x 140mm
Overall Height	581mm
Motor	150W
Weight	21kg
